Flue pressure testing machine

The microcomputer-controlled flue pressure testing machine is mainly used to test the mechanical properties of glass fiber reinforced cement exhaust pipe finished products. It complies with the standard requirements of "JC/T854-2008" and can be used to test the compressive strength of exhaust pipes.This testing machine uses a microcomputer to control the loading, and the continuous loading is stable. It has automatic display of experimental data, automatic collection and storage of data, drawing of curves, and automatic printing of test reports. The computer controls the test process in a timely manner, displays the test force and test curve, and is simple, reliable, and easy to operate.And using high-precision sensors to measure, the performance of the whole machine is stable and reliable.

Main technical indicators

1. Host structure: frame type

2. Test force: 300KN

3. Test force accuracy: ≤±1%

3. Operation method: Computer operation in Chinese

4. Test force classification: 4th grade

5. Measurement range: 2%-100% of test force

6. Accuracy level: Level 1

7. Test force accuracy: better than ±1% of the indicated value

8. Force resolution: 0.1N

9. Displacement measurement: resolution is 0.01mm

10. Space adjustment mechanism: motor, adjustment range 500mm

11. Piston no-load moving speed: 0～60 mm/min;

12. Piston loading and moving speed: 0～60 mm/min;

13. Lifting and lowering speed: about 150 mm/min

14. Piston stroke: 200mm

15. Column spacing 550mm (can be customized according to customer needs)

16. Compression space: 500*800*1200mm (can be customized according to customer needs)

17. Pressure plate size: 500*800

18. Appearance: Comply with national GB/T2611 standard
