Lightning arrester bending tensile testing machine

Huayan's microcomputer-controlled arrester bending tensile testing machine is mainly used to test the mechanical properties of arresters such as tension, compression, and bending.The bending and tensile performance test of the arrester can be completed by configuring special arrester bending and tensile auxiliary equipment. It is mainly used for bending strength testing of various types of arresters such as zinc oxide arresters, valve-type arresters, and tube-type arresters.The system adopts microcomputer closed-loop control, has a wide and accurate loading speed and force measurement range, and has high accuracy and sensitivity for the measurement and control of load and displacement.This equipment is applicable to experimental standards such as GB/T11032-2016 "AC Gapless Metal Oxide Lightning Arrester", JB-T 8952-2018 "Composite Jacketed Gapless Metal Oxide Lightning Arrester for AC Systems" and GB 11032-2016 "Metal Zinc Oxide Lightning Arrester".

Technical parameters

1. Maximum test force: 100KN (adjustable)

2. Accuracy level: Level 1

3. Structural form: aluminum alloy frame

4. Allowable error limit of test force indication: within ±1% of the indication value

5. Load measurement range: 2% ~ 100% FS of full scale

6. Force resolution: 1/300000 of the maximum test force

7. Limit error of displacement indication: within ±1% of indication

8. Minimum resolution of displacement: 0.01mm

9. Cross beam speed adjustment range: 0.05~500mm/min

10. Relative error of beam speed: within ±1% of the set value

11. Effective test width: 450mm (adjustable)

12. Effective stretching space distance: 650mm (adjustable)

13. Host overall dimensions: about 900*480*1950mm

14. Host weight: about 250kg

15.Power supply: 220V, 0.75KW

16. Software and user interface: software and interactive human-computer dialogue operation interface under WINDOWS operating environment

17. The test process, measurement, display, analysis, control, etc. are all completed by microcomputer

18. After the sample is damaged, the moving beam automatically stops moving (or automatically returns to the initial position)

19. With program-controlled and mechanical two-level limit protection

20. When the load exceeds the rated value by 3~5%, it will automatically stop
