1.Product introduction
Tensile and torsion testing machines are mainly used to test the dynamic and static mechanical properties of tiny metals, non-metallic materials and components, elastomers, and shock absorbers.Can realize sine wave, triangle wave, square wave and other waveforms.Equipped with different fixtures, mechanical tests such as tension, compression, tension and compression, and tension and torsion can be performed.
The testing machine consists of an electrical controller, an electric cylinder, a load sensor, a displacement sensor, a torsion drive device, test software and a computer to form a closed-loop control system to achieve automatic and precise control of the test process, and automatically measure test force, torque, displacement, deformation and other test parameters.The test process is all under computer control, making it an ideal and cost-effective test system for scientific research institutes, metallurgical construction, national defense industry, universities, machinery manufacturing, transportation and other industries.
The test mode can support: uniaxial tension, uniaxial compression, tension torsion, compression torsion, and torsion fatigue tests.It can support customized test plans and draw force-displacement and stress-strain curves in real time.Supports automatic sensor calibration and real-time parameter adjustment.
2.Main technical indicators:
Specifications and models | parameters |
Maximum static test force (kN) | 100 |
Maximum dynamic test force (kN) | ±100 |
Maximum torque (N.M) | 300 |
Maximum speed rpm | 3000 |
Test force measurement range (N) | (2%～100%FS) |
Test force indication error | 0.5% |
Actuator stroke (mm) | 100 |
Displacement measurement range (mm) | 0～100(±50) |
Displacement measurement resolution | 0.015μm |
Relative error of displacement measurement indication | 0.5% |
Deformation rate adjustment range | 0.02～5%FS/S |
Test frequency (Hz) | 0.01～10 (refer to the amplitude-frequency characteristic table) |
Test waveform | Sine wave, triangle wave, square wave, etc. |
Maximum stroke of crossbeam (mm) (distance between upper/lower clamp end faces) | 800 |
Maximum speed of beam adjustment (mm/min) | 700 |
Relative error of beam adjustment speed | 0.2% |
Clear distance between columns (mm) | 520 |
Host size (mm) | 1300×950×2300 |
Host net weight (kg) | About 1350 |
Control cabinet size (mm) | 800×600×1800 |
Total power(kW) | 7 |
1.Equipment scope of supply
serial number | Part name | Description | Quantity | unit | Manufacturer |
1 | Host | ||||
1.1 | Frame type high rigidity host | Actuator mounted on top/T-shaped table mounted on bottom; maximum force 100kN | 1 | Taiwan | Shandong Huayan |
1.2 | force sensor | ±100kN fatigue level | 1 | pieces | American Quanli |
2 | Electric cylinder assembly | ||||
2.1 | Servo motor | 6kW | 1 | Taiwan | Panasonic |
2.2 | Electric cylinder | 100kN, stroke 100mm | 1 | Taiwan | |
2.3 | Torsion test device | 300N.M/3000 rpm | 1 | set | |
3 | Controls and software | ||||
3.1 | control cabinet | Integrated vertical control cabinet | 1 | Taiwan | totem cabinet |
3.2 | controller | Fully digital closed-loop electrical system | 1 | Taiwan | Shandong Huayan |
3.3 | industrial computer | Core I5, 8GB memory, 1T hard drive | 1 | set | Advantech |
3.4 | industrial display | LCD display | 1 | Taiwan | |
3.5 | Test software | Huayan test test software and CD | 1 | set | Shandong Huayan |
4 | fixture | ||||
4.1 | fixture | Customized according to customer samples | 1 | set | Shandong Huayan |
5 | A set of special tools | one wordand1 Phillips screwdriver each; 1 set of Allen wrenches, 2 pieces of robot hand | 1 | Taiwan | Shandong Huayan |
6 | Product certificate | 1 | portion | Shandong Huayan | |
7 | Product instruction manual | 1 | portion | Shandong Huayan |
2.Equipment details
Host introduction
The main machine adopts a closed frame structure, and the outer surface of the double columns is electroplated with hard chrome.It adopts the design of upper-mounted servo actuator and lower-mounted T-shaped table, which has strong test scalability.
1.The main machine adopts a closed T-shaped frame structure. The frame has high rigidity, no backlash, and good stability;
2.The bottom T-shaped table has high strength and strong expansibility, and can be installed with test fixtures to achieve static and dynamic fatigue mechanics testing of various standard specimens; it can also be directly installed with various components and structural parts to achieve dynamic and static mechanical testing;
3.The servo actuator is mounted on the top and adopts a double-acting non-contact servo motor. It has the advantages of compact structure, small size, no need for lubricating oil and hydraulic oil, clean environment, no noise, and maintenance-free;
4.The up and down movement of the beam is electrically adjusted to meet the mechanical testing of different types of specimens.
5.Equipped with self-diagnosis system indicator light and LCD handheld operator;
Electric cylinder assembly:The electric cylinder is a power mechanism that loads the specimen, and the servo motor drives the ball screw to form a linear push/pull force.Parameters:
● Maximum test force: 100kN
● Stroke: 100mm
● Servo motor power: 6kW
● Servo motor brand: Panasonic, Japan
High-precision force and torque composite sensor:
The sensor system of this equipment is equipped with a high-precision force measurement and torque composite sensor, with a uniaxial tension/compression load range of 100kN and a maximum torsion torque of 300N·m; an error of 0.5%; it integrates axial tension pressure measurement and torsion torque measurement, and can meet the needs of uniaxial tension, uniaxial compression, tension torsion, and compression.For high-precision and high-dynamic measurement requirements in various test modes such as torsion and torsional fatigue, the torque composite sensor can achieve fatigue loading with a resolution of 0.5N.m, a linkage tension/compression sensing accuracy resolution of 10N, and a dynamic control accuracy of 0.5%; the cycle number is 50,000 times, and the cycle frequency is 200Hz.
control cabinet
The vertical integrated control cabinet integrates important components such as industrial computers and monitors, fully digital closed-loop controllers, printers, and power supplies, and occupies a small area. It has anti-vibration, anti-impact, corrosion-resistant, dust-proof, radiation-proof and other functions to ensure stable and reliable operation of each component.
controller
1.The controller uses the industry's highest ultra-high-speed ARM chip based on the Cortex-M7 core as the main control chip, with a main frequency of up to 480MHz. It has extremely high computing speed and data processing capabilities. It can realize the entire control process from data collection, PID calculation, network communication to output control in a short time, thereby achieving precise closed-loop control of the testing machine;
2.The controller supports remote firmware upgrade to achieve more customized functions;
3.Input channel:
1)3 channels of high-precision 24-bit A/D conversion channels, the sampling frequency can reach up to 2500 Hz, the resolution can reach 1/500000, and each sensor supports multi-point correction;
2)2 channels of orthogonal encoding digital input channels, 1 channel uses 10M/Bit optocoupler input for differential wire pull encoder or servo motor encoder acquisition, and the other 2 channels are used for large deformation interface;
3)1 SSI Gray code dedicated channel supports common digital magnetostrictive sensors;
4)8-channel digital input port can be configured as limit emergency stop and other functions, and can be used with a dedicated manual control box to realize more external functions.
4.Output channel:
1)1 SWP output, 0-1Mhz, used for servo motor speed control, can be configured as dual-channel to control 2 motors at the same time;
2)1 PNM output, precise pulse output, supports open-loop motion control (ramp wave, sine wave, etc.);
3)6 channels of DO output, RS422 differential output.
5.Network communication:
1)Industrial Ethernet interface: 10/100Mbps rate;
2)Industrial RS485 interface: supports MODBUS and HMI interconnection.
6.Data saving: This controller will automatically save the debugged measurement and control parameters, and will not lose the debugged measurement and control parameters (non-experimental data) because the user changes the computer at will.
7.The control system supports smart sensor functions, and supports automatic identification of the range and calibration parameters of sensors and extensometers when using multiple sensors, plug and play; supports real-time parameter adjustment, and supports measurement unit switching.
8.Non-contact strain measurement systems (such as DIC digital speckle correlation method), high and low temperature environmental chambers, etc. can be integrated for multi-field coupling testing.
